Diesel tsav lub tshuab hluav taws xob teeb tsa rau cov ntawv thov hauv Cheeb Tsam 2 (Zoo 2) mounted hauv DNV ntawv pov thawj 2.7-1 Skid thav duab enclosure ua 60KVA @ 0.8 pf, 400VAC, 3 Theem + Nruab Nrab, 50HZ tso zis
Quality & Ua raws li:
Cov khoom lag luam Ex yuav ua raws li ATEX tus qauv EN 60079 series thiab EN 1834 series, thiab yuav muab ib daim ntawv tshaj tawm ntawm kev sib haum xeeb uas tau kos npe los ntawm cov chaw tsim khoom raws li ATEX Standard EN 1834-1.
Lub 60KVA Zone 2 Hazardous Area Diesel Generator yog ib qho kev nyab xeeb - tsom lub zog daws teeb meem rau ib puag ncig uas muaj cov pa hluav taws xob / vapors qee zaus (xws li cov chaw mining, petrochemical auxiliaries, siab - kev cob qhia kev pheej hmoo). Nws ua tau raws li ATEX / IECEx tawg- cov qauv pov thawj, nrog rau cov khoom tseem ceeb kaw thiab cov pa hluav taws xob tiv thaiv kom tsis txhob muaj hluav taws kub / siab - qhov kub thiab txias ignition.
Nrog 60KVA muaj peev xwm (48KW nquag zog, 0.8 PF) thiab 400VAC 3-theem tso zis, nws suits industrial hnyav loads. Peb muab cov kev daws teeb meem tsim nyog: mine plua plav-cov ntaub ntawv pov thawj tsim, petrochemical gas- saib xyuas kev teeb tsa, thiab lub tshuab hluav taws xob xwm txheej ceev rau kev cob qhia. Customization suav nrog kev hloov pauv voltage / zaus, siab -qhov siab hloov pauv, thiab ntxiv -ons xws li kev tswj chaw taws teeb. Tom qab-Kev muag khoom suav nrog kev tshawb fawb ntawm qhov chaw thiab kev saib xyuas kom ntseeg tau tias kev ua haujlwm tau zoo, ua raws.
|
Qauv |
EADG60-EX2 |
|
Ua kom tiav tshuab |
|
|
Kev tawg- pov thawj Mark |
|
|
Cheeb tsam xwm txheej |
ZONE 2 |
|
Daim ntawv pov thawj |
《Kev tshaj tawm ntawm kev sib haum xeeb nthuav qhia |
|
Cov khoom tsim tawm tsim tawm (0.8 pf 25ºC) |
60KVA 380V / 50HZ Cov |
|
Max. Lub kaum sab xis ua haujlwm |
15 degree |
|
Lub suab nrov (± 3 dBA ntawm 7m) |
75 |
|
Tshuab Luj (kg) |
2500 (hli) |
|
Medidas: L x W x H mm |
3412X2200X2256 |
|
Roj tank |
>300L |
|
DIESEL ENGINE |
|
|
Qauv |
6BT5.9-G2 |
|
Kev ceev ceev (rpm) |
1500/1800 |
|
Prime hwj chim (kW) |
96 kW @ 1500 rpm |
|
Kev tshem tawm (L) |
5.9 |
|
No. ntawm lub tog raj kheej |
6 |
|
Cav Roj Peev Xwm (L) |
18 |
|
Hluav taws xob qhov system Voltage (V) |
24 |
|
Rated Peev Xwm ntawm Roj Teeb |
120Ah/ua |
|
GENERATORS |
|
|
Chaw tsim tshuaj paus |
Kingway OEM |
|
Kev tawg- pov thawj Mark |
|
|
Daim ntawv pov thawj naj npawb |
《Kev tshaj tawm ntawm kev sib haum xeeb nthuav qhia |
|
Cheeb tsam xwm txheej |
ZONE 2 |
|
Ambient kub |
-25℃~ +60 degree |
|
Qhov siab |
Tsawg dua lossis sib npaug li 1000M |
|
Rated Voltage |
380V (50HZ) |
|
Rated Zaus |
50 HZ |
|
Rated REV |
1500 RPM |
|
Hwj chim Factor |
0.8 LOJ |
|
Kev ua haujlwm |
Nruam (S1) |
|
IP Qib |
IP66 |
|
Tus tswj |
ComAp MRS 16 |
II 3G IIB T3 Gc
II 3G Ex nA IIB T3 IP54
